製品一覧表
Personal Computer Recommended Microphones
ENTRY TIER
VDD=1.6V~3.6V VDD 1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| TOP | ZTS6231 | -26/-26dBFS+/-1dB | 4.0×3.0x1.0mm | 64dBA | 50Hz | 115dBSPL/120dBSPL | 800uA |
|
3.8 |
| ZTS6531S | -26/-26dBFS+/-1dB | 4.0×3.0x1.0mm | 65dBA | 50Hz | 110dBSPL/120dBSPL | 350uA/950uA |
|
3.6 | |
| ZTS6234 | -26/-26dBFS+/-1dB | 4.0×2.0x1.02mm | 64dBA | 50Hz | 116dBSPL/120dBSPL | 800uA |
|
2.2 | |
| ZTS6534 | -26/-26dBFS+/-1dB | 4.0×2.0x1.1mm | 65.5dBA | 50Hz | 110dBSPL/120dBSPL | 350uA/950uA |
|
2.5 | |
| ZTS6535 | -26/-26dBFS+/-1dB | 3.5×2.0x1.0mm | 64dBA | 50Hz | 115dBSPL/122dBSPL | 350uA/800uA |
|
1.7 | |
| ZTS6536 | -26/-26dBFS+/-1dB | 3.5×1.6×1.3mm | 65dBA | 50Hz | 117dBSPL/120dBSPL | 250uA/900uA |
|
2.1 | |
| ZTS6537 | -26/-26dBFS+/-1dB | 4.0×1.3×1.3mm | 64dBA | 50Hz | 117dBSPL/121dBSPL | 200uA/600uA |
|
1 | |
| BOTTOM | ZTS6572S | -26/-26dBFS+/-1dB | 3.5×2.65×0.98mm | 64dBA | 50Hz | 114dBSPL/120dBSPL | 300uA/800uA |
|
3.8 |
| ZTS6575 | -26/-26dBFS+/-1dB | 3.5×2.0x1.0mm | 65dBA | 50Hz | 116dBSPL/120dBSPL | 300uA/850uA |
|
1.6 | |
| SIDE | ZTS6541 | -37/-21dBFS+/-1dB | 4.0×3.0x1.25mm | 65dBA | 50Hz | 110dBSPL/120dBSPL | 250uA/800uA |
|
2.3 |
| ZTS6544 | -26/-26dBFS+/-1dB | 4.0×2.0x1.1mm | 64dBA | 50Hz | 110dBSPL/120dBSPL | 300uA/800uA |
|
1.4 |
HIGH PERFORMANCE
VDD=1.6V~3.6V VDD 1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| TOP | ZTS6531SA | -26/-26dBFS+/-1dB | 4.0×3.0x1.0mm | 67dBA | 50Hz | 110dBSPL/120dBSPL | 250uA/800uA |
|
1.9 |
| ZTS6534S | -26/-26dBFS+/-1dB | 4.0×2.0x1.02mm | 68dBA | 30Hz | 116dBSPL/120dBSPL | 350uA/800uA |
|
1.1 | |
| ZTS6535SE | -26/-26dBFS+/-1dB | 3.5×2.0x1.0mm | 67dBA | 50Hz | 115dBSPL/120dBSPL | 350uA/800uA |
|
1.5 | |
| ZTS6731 | -26/-26dBFS+/-1dB | 4.0×3.0x1.0mm | 70dBA | 50Hz | 115dBSPL/120dBSPL | 440uA/800uA |
|
2.1 | |
| ZTS6734 | -26/-26dBFS+/-1dB | 4.0×2.0x1.1mm | 70dBA | 50Hz | 116dBSPL/120dBSPL | 350uA/800uA |
|
1.6 | |
| BOTTOM | ZTS6872SE | -26/-26dBFS+/-1dB | 3.5×2.65×0.98mm | 68dBA | 50Hz | 114dBSPL/120dBSPL | 300uA/800uA |
|
2.1 |
| ZTS6575SE | -26/-26dBFS+/-1dB | 3.5×2.0x1.0mm | 67dBA | 50Hz | 110dBSPL/120dBSPL | 300uA/850uA |
|
1.3 | |
| SP | ZTS6544SE | -26/-26dBFS+/-1dB | 4.0×2.0x1.1mm | 69dBA | 50Hz | 116dBSPL/120dBSPL | 350uA/800uA |
|
1.4 |
SOUNDWIRE MICROPHONE
VDD=1.6V~3.6V VDD 1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| TP | ZTS6872SE | -26/-26dBFS+/-1dB | 3.5×2.65×0.98mm | 68dBA | 50Hz | 114dBSPL/120dBSPL | 300uA/800uA |
|
2.1 |
| BP | ZTS6544SE | -26/-26dBFS+/-1dB | 4.0×2.0x1.1mm | 69dBA | 50Hz | 116dBSPL/120dBSPL | 350uA/800uA |
|
1.4 |
MOBILE PHONE WEARABLE Recommended Microphones
ENTRY TIER
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6856S | -38dBV+/-1dB | 2.75×1.85×0.9mm | 63dBA | 35Hz | 110dBSPL/130dBSPL | 120uA |
|
2.1 |
| ZTS6856 | -42dBV+/-1dB | 2.75×1.85×0.9mm | 64.5dBA | 35Hz | 130dBSPL/132dBSPL | 120uA |
|
2.0 | |
| ZTS6056 | -38dBV+/-1dB | 2.75×1.85×0.9mm | 64dBA | 15Hz | 120dBSPL/130dBSPL | 120uA |
|
2.3 | |
| DIGITAL | ZTS6872C | -37/-21dBFS+/-1dB | 3.5×2.65×0.98mm | 65.5dBA | 50Hz | 127dBSPL/133dBSPL | 260uA/850uA |
|
2.1 |
| ZTS6577S | -37/-21dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 75Hz | 120dBSPL/133dBSPL | 280uA/850uA |
|
1.8 |
HIGH PERFORMANCE
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6856E | -40dBV+/-1dB | 2.75×1.85×0.9mm | 66dBA | 35Hz | 130dBSPL/132dBSPL | 120uA |
|
1.0 |
| ZTS6853E | -40dBV+/-1dB | 3.50×2.65×0.98mm | 70dBA | 35Hz | 130dBSPL/136dBSPL | 120uA |
|
1.0 | |
| ZTS6872 | -37/-21dBFS+/-1dB | 3.50×2.65×0.98mm | 68dBA | 75Hz | 130dBSPL/133dBSPL | 100uA/300uA |
|
3.0 | |
| ZTS6872E | -35/-21dBFS+/-1dB | 3.50×2.65×0.98mm | 68dBA | 35Hz | 120dBSPL/132dBSPL | 250uA/850uA |
|
1.7 | |
| ZTS6577E | -37/-26dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 35Hz | 118dBSPL/120dBSPL | 300uA/800uA |
|
1.0 |
Headset & TWS Recommended Microphones
ENTRY TIER
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6156
|
-38dBV+/-1dB | 2.75×1.85×0.9mm | 63dBA | 75Hz | 120dBSPL/132.5dBSPL | 120uA |
|
2.0 |
ZTS6015
|
-42dBV+/-1dB | 3.76×2.24×1.1mm | 59dBA | 75Hz | 120dBSPL/132dBSPL | 120uA |
|
1.8 | |
| ZTS6016
|
-42dBV+/-1dB | 3.10×2.50×1.0mm | 59dBA | 75Hz | 120dBSPL/128dBSPL | 65uA |
|
1.8 | |
| ZTS6117
|
-42dBV+/-1dB | 2.75×1.85×0.95mm | 59dBA | 75Hz | 120dBSPL/130dBSPL | 120uA |
|
1.6 | |
ZTS6053
|
-38dBV+/-1dB | 3.5×2.65×0.98mm | 65dBA | 10Hz | 118dBSPL/130dBSPL | 120uA |
|
3.2 | |
| ZTS6055
|
-38dBV+/-1dB | 2.75×1.85×0.9mm | 64dBA | 15Hz | 115dBSPL/125dBSPL | 120uA |
|
2.3 | |
| ZTS6127
|
-38dBV+/-1dB | 2.75×1.85×1.0mm | 59dBA | 75Hz | 118dBSPL/130dBSPL | 120uA |
|
1.5 | |
| DIGITAL | ZTS6538
|
-26/-26dBFS+/-1dB | 2.75×1.85×0.9mm | 61dBA | 50Hz | 100dBSPL/120dBSPL | 300uA/600uA |
|
1.4 |
| ZTS6548
|
-26/-26dBFS+/-1dB | 2.75×1.85×0.9mm | 61dBA | 50Hz | 100dBSPL/120dBSPL | 300uA/800uA |
|
1.0 | |
| ZTS6578
|
-26/-26dBFS+/-1dB | 2.55×1.60×0.95mm | 63dBA | 50Hz | 114dBSPL/120dBSPL | 170uA/400uA |
|
1.4 | |
| ZTS6577
|
-26/-26dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 25Hz | 114dBSPL/120dBSPL | 300uA/800uA |
|
1.4 | |
| ZTS6777
|
-26/-26dBFS+/-1dB | 2.75×1.85×0.95mm | 66dBA | 25Hz | 114dBSPL/120dBSPL | 300uA/800uA |
|
1.0 |
ANC ENTRY TIER
VDD=1.5V(A)/1.62V ( D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6216 | -38dBV+/-1dB | 2.75×1.85×1.0mm | 64dBA | 5Hz | 116dBSPL/130dBSPL | 120uA |
|
2.8 |
| ZTS6216S | -38dBV+/-1dB | 2.75×1.85×1.0mm | 66dBA | 5Hz | 116dBSPL/130dBSPL | 120uA |
|
1.1 | |
| ZTS6117SE | -38dBV+/-1dB | 2.75×1.85×0.9mm | 60dBA | 5Hz | 120dBSPL/132dBSPL | 120uA |
|
1.2 | |
| ZTS6211E | -38dBV+/-1dB | 3.76×2.95×1.1mm | 65dBA | 15Hz | 122dBSPL/132dBSPL | 120uA |
|
2.7 | |
| ZTS6156SE | -38dBV+/-1dB | 2.75×1.85×0.9mm | 64dBA | 5Hz | 118dBSPL/130dBSPL | 120uA |
|
1.5 | |
| ZTS6127SE | -38dBV+/-1dB | 2.75×1.85×1.0mm | 60dBA | 25Hz | 120dBSPL/130dBSPL | 120uA |
|
1.7 | |
| ZTS6226 | -38dBV+/-1dB | 2.75×1.85×1.25mm | 64dBA | 25Hz | 118dBSPL/130dBSPL | 120uA |
|
1.1 | |
| ZTS6856SE | -38dBV+/-1dB | 2.75×1.85×0.9mm | 64dBA | 25Hz | 120dBSPL/130dBSPL | 120uA |
|
2.5 | |
| DIGITAL | ZTS6872C | -37/-21dBFS+/-1dB | 3.50×2.65×0.98mm | 65.5dBA | 50Hz | 127dBSPL/133dBSPL | 260uA/850uA |
|
2.1 |
| ZTS6538SE | -26dBFS+/-1dB | 2.75×1.85×1.25mm | 65dBA | 25Hz | 116dBSPL/120dBSPL | 300uA/800uA |
|
1.9 | |
| ZTS6538S | -37/-21dBFS+/-1dB | 2.75×1.85×1.25mm | 65dBA | 25Hz | 116dBSPL/132.5dBSPL | 250uA/850uA |
|
2.0 | |
| ZTS6577S | -37/-21dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 35Hz | 114dBSPL/133dBSPL | 280uA/850uA |
|
1.8 |
ANC HIGH PERFORMANCE
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6752 | -34.7dBV+/-1dB | 4.72×3.76×1.15mm | 70dBA | 25Hz | 120dBSPL/135dBSPL | 250uA |
|
2.0 |
ZTS6654
|
-38dBV+/-1dB | 3.35×2.5×0.96mm | 67dBA | 25Hz | 120dBSPL/135dBSPL | 250uA |
|
1.7 | |
| ZTS6756SE | -38dBV+/-1dB | 2.75×1.85×1.2mm | 67dBA | 25Hz | 120dBSPL/135dBSPL | 120uA |
|
2.0 | |
| DIGITAL | ZTS6872E | -35/-21dBFS+/-1dB | 3.5×2.65×0.98mm | 68dBA | 35Hz | 120dBSPL/132dBSPL | 250uA/850uA |
|
1.7 |
| ZTS6577E | -37/-21dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 35Hz | 118dBSPL/120dBSPL | 300uA/800uA |
|
1.0 |
SPECILITY
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6411E
|
-38dBV+/-1dB | 3.76×2.95×1.25mm | 65dBA | 15Hz | 105dBSPL/128dBSPL | 80uA |
|
1.5 |
ZTS6416
|
-38dBV+/-1dB | 2.75×1.85×1.1mm | 65dBA | 25Hz | 116dBSPL/130dBSPL | 19uA |
|
1.8 | |
ZTS6615
|
-42dBV+/-1dB | 3.76×2.24×1.1mm | 59dBA | 25Hz | 116dBSPL/120dBSPL | 125uA |
|
2.2 | |
ZTS6083
|
-38dBV+/-1dB | 11.5×6.5×2.1mm | 60dBA | 25Hz | 105dBSPL/123dBSPL | 600uA |
|
1.1 | |
| DIGITAL | ZTS6431E
|
-26dBFS+/-1dB | 4.0×3.0x1.15mm | 65dBA | 35Hz | 116dBSPL/120dBSPL | 300uA/800uA |
|
1.9 |
| ZTS6577E | -37/-21dBFS+/-1dB | 2.75×1.85×0.95mm | 64dBA | 35Hz | 118dBSPL/120dBSPL | 300uA/800uA |
|
1.0 |
Hearing Aids Recommended Microphones
ENTRY TIER
VDD=0.9V~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6556S | -35dBV+/-1dB | 2.75×1.85×0.9mm | 65.5dBA | 75Hz | 120dBSPL/125dBSPL | 26uA |
|
1.5 |
| ZTS6516
|
-35dBV+/-1dB | 2.75×1.85×1.0mm | 64dBA | 75Hz | 110dBSPL/125dBSPL | 26uA |
|
1.7 | |
| ZTS6516E | -35dBV+/-1dB | 2.75×1.85×1.1mm | 64dBA | 75Hz | 110dBSPL/125dBSPL | 26uA |
|
1.2 | |
| ZTS6526 | -35dBV+/-1dB | 2.75×1.85×1.25mm | 64dBA | 50Hz | 112dBSPL/123dBSPL | 26uA |
|
1.8 | |
| Digital | ZTSL6577 | -26/-26dBFS+/-1dB | 2.75×1.85×0.95mm | 65dBA | 50Hz | 114dBSPL/120dBSPL | 150uA/300uA |
|
1.5 |
| ZTSL6577SE | -29dBFS+/-1dB | 2.75×1.85×0.95mm | 65dBA | 25Hz | 120dBSPL/125dBSPL | 150uA/350uA |
|
1.3 | |
| ZTSL6538 | -26/-26dBFS+/-1dB | 2.75×1.85×1.1mm | 64dBA | 50Hz | 115dBSPL/122dBSPL | 150uA/300uA |
|
1.4 | |
| ZTSL6538S | -37/-21dBFS+/-1dB | 2.75×1.85×1.2mm | 65dBA | 50Hz | 116dBSPL/132dBSPL | 350uA/850uA |
|
1.0 | |
| ZTSL6538SE | -29dBFS+/-1dB | 2.75×1.85×1.1mm | 64dBA | 50Hz | 100dBSPL/125dBSPL | 150uA/350uA |
|
1.3 |
HIGH PERFORMANCE
VDD=0.9V~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6554S | -35dBV+/-1dB | 3.35×2.50×0.96mm | 67.5dBA | 75Hz | 110dBSPL/120dBSPL | 26uA |
|
1.9 |
| ZTS6554SE | -35dBV+/-1dB | 3.35×2.50×0.96mm | 69dBA | 75Hz | 110dBSPL/120dBSPL | 19uA |
|
1.3 | |
| ZTS6514 | -35dBV+/-1dB | 3.35×2.50×1.3mm | 68dBA | 75Hz | 110dBSPL/120dBSPL | 19uA |
|
1.2 | |
| ZTS6524 | -36dBV+/-1dB | 3.35×2.50×1.20mm | 67dBA | 75Hz | 110dBSPL/120dBSPL | 26uA |
|
1.2 | |
| ZTS6524S | -35dBV+/-1dB | 5.22×2.50×2.30mm | 69dBA | 75Hz | 110dBSPL/120dBSPL | 19uA |
|
1.1 |
Internet Of Thing Recommended Microphones
ENTRY TIER
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6853 | -38dBV+/-1dB | 3.50×2.65×0.98mm | 65dBA | 75Hz | 110dBSPL/130dBSPL | 120uA |
|
1.8 |
| ZTS6211E | -38dBV+/-1dB | 3.76×2.95×1.1mm | 65dBA | 15Hz | 122dBSPL/132dBSPL | 250uA |
|
2.7 | |
| ZTS6051E | -38dBV+/-1dB | 3.76×2.95×1.1mm | 65dBA | 25Hz | 105dBSPL/130dBSPL | 100uA |
|
2.5 | |
| ZTS6011E | -42dBV+/-1dB | 3.76×2.95×1.1mm | 59dBA | 25Hz | 110dBSPL/128dBSPL | 120uA |
|
2.4 | |
| ZTS6856 | -42dBV+/-1dB | 2.75×1.85×1.0mm | 64.5dBA | 35Hz | 130dBSPL/132dBSPL | 120uA |
|
2.0 | |
| DIGITAL | ZTS6031 | -26dBFS+/-1dB | 4.0×3.0×1.06mm | 61dBA | 35Hz | 115dBSPL/120dBSPL | 800uA |
|
3.3 |
| ZTS6032M | -22dBFS+/-1dB | 4.72×3.76×1.25mm | 61dBA | 35Hz | 112dBSPL/116dBSPL | 800uA |
|
1.4 | |
| ZTS6131S | -26/-26dBFS+/-1dB | 4.0×3.0x1.06mm | 64dBA | 75Hz | 120dBSPL/120dBSPL | 300uA/800uA |
|
2.4 | |
| ZTS6531S | -26/-26dBFS+/-1dB | 4.0×3.0x1.0mm | 65dBA | 75Hz | 120dBSPL/120dBSPL | 350uA/950uA |
|
3.6 | |
| ZTS6232 | -22/-22dBFS+/-1dB | 4.72×3.76×1.25mm | 65dBA | 75Hz | 112dBSPL/116dBSPL | 800uA |
|
1.6 | |
| ZTS6872C | -37/-21dBFS+/-1dB | 3.50×2.65×0.98mm | 65.5dBA | 50Hz | 127dBSPL/133dBSPL | 260uA/850uA |
|
2.1 | |
| ZTS6872S | -26/-26dBFS+/-1dB | 3.50×2.65×0.98mm | 65dBA | 75Hz | 114dBSPL/123dBSPL | 300uA/850uA |
|
2.1 |
HIGH PERFORMANCE
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6753 | -38dBV+/-1dB | 3.50×2.65×0.98mm | 69.5dBA | 75Hz | 112dBSPL/135dBSPL | 120uA |
|
2.4 |
| ZTS6752 | -34.7dBV+/-1dB | 4.72×3.76×1.15mm | 70dBA | 25Hz | 120dBSPL/135dBSPL | 250uA |
|
2.0 | |
| ZTS6752SE
|
-36dBV+/-1dB | 4.72×3.76×1.15mm | 74dBA | 25Hz | 120dBSPL/135dBSPL | 250uA |
|
1.1 | |
| DIGITAL | ZTS6772 | -26dBFS+/-1dB | 3.50×2.65×0.98mm | 70dBA | 35Hz | 114dBSPL/120dBSPL | 250uA/850uA |
|
2.4 |
| ZTS6772S | -37/-21dBFS+/-1dB | 3.50×2.65×0.98mm | 69dBA | 35Hz | 114dBSPL/130dBSPL | 250uA/850uA |
|
1.5 |
SPECILITY
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTS6653
| -38dBV+/-1dB | 3.10×2.5×0.85mm | 65dBA | 75Hz | 128dBSPL/135dBSPL | 200uA |
|
1.3 |
| ZTS6088 | -35dBV+/-1dB | 11.5×6.5×2.10mm | 60dBA | 25Hz | 105dBSPL/120dBSPL | 600uA |
|
1.4 | |
| DIGITAL | ZTS6431E | -26dBFS+/-1dB | 4.0×3.0x1.15mm | 65dBA | 35Hz | 116dBSPL/120dBSPL | 300uA/800uA |
|
1.9 |
ZTS6672
|
-26dBFS+/-1dB | 3.50×2.65×0.98mm | 64dBA | 35Hz | 116dBSPL/120dBSPL | 800uA |
|
2.9 | |
| ZTS6631
|
-26/-26dBFS+/-1dB | 4.00×3.00×1.00mm | 64dBA | 35Hz | 116dBSPL/120dBSPL | 925uA |
|
3.1 |
Automotive Recommended Microphones
ENTRY TIER
VDD=1.5V(A)/1.62V(D)~3.6V VDD 0.1uF Capacitor Decoupling
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | Rev | ||
| ANALOG | ZTSQ6853 | -38dBV+/-0.5dB | 3.50×2.65×0.98mm | 64dBA | 75Hz | 118dBSPL/130dBSPL | 120uA |
|
1.2 |
| ZTSQ6811 | -38dBV+/-0.5dB | 3.76×2.95×1.1mm | 65dBA | 25Hz | 132dBSPL/110dBSPL | 120uA |
|
1.0 | |
| ZTSQ6813 | -38dBV+/-0.5dB | 3.5×2.65×1.0mm | 65dBA | 15Hz | 120dBSPL/130dBSPL | 120uA |
|
1.1 | |
| ZTSQ6051 | -38dBV+/-0.5dB | 3.76×2.95×1.1mm | 65dBA | 25Hz | 110dBSPL/125dBSPL | 120uA |
|
1.1 | |
| ZTSQ6011 | -42dBV+/-0.5dB | 3.76×2.95×1.1mm | 59dBA | 25Hz | 110dBSPL/130dBSPL | 85uA |
|
1.1 | |
| DIGITAL | ZTSQ6831S | -26/-26dBFS+/-0.5dB | 4.0×3.0x1.0mm | 67dBA | 50Hz | 110dBSPL/120dBSPL | 250uA/800uA |
|
1.2 |
| ZTSQ6872S | -26/-26dBFS+/-0.5dB | 3.50×2.65×0.98mm | 64dBA | 75Hz | 114dBSPL/120dBSPL | 350uA/700uA |
|
1.0 |
MODULE
| MICROPHONE | SENSITIVITY | SIZE | SNR | LFRO | 1%/10% THD | CURRENT | |
ZTSQM6872S  |
-26/-26dBFS+/-1dB | 3.50×2.65×0.98mm | 64dBA | 75Hz | 114dBSPL/120dBSPL | 2mA |
その他の電子部品
電子部品に
関するお問い合わせ
製品に関するご質問・ご商談等お問い合わせ
お問い合わせフォームお電話でのお問い合わせ
03-6412-5082
